BF15-20HP SPECIFICATION SHEET
-
BF15 SHU
-
Feature
-
Engine
-
Engine Type OHC - 2 cylinders
-
Valves 4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 4,500 - 6,000
-
Rated Power (kW (PS))11
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery 1 carburettor with accelerator pump
-
Ignition System Electronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust System Through propeller boss
-
Gear Ratio 2.08
-
Propeller Rotation Standard
-
Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
-
Function
-
Electric Starter Y
-
Battery Charging Capacity (AMP.) 12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm) 433
-
Dry Weight (kg) 46.5
-
Overall Length (mm)650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1110
-
With a 433mm shaft and 6A battery.
​

​
-
BF15 LHU
-
Feature
-
Engine
-
Engine Type OHC - 2 cylinders
-
Valves 4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 4,500 - 6,000
-
Rated Power (kW (PS)) 11
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery 1 carburettor with accelerator pump
-
Ignition System Electronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust System Through propeller boss
-
Gear Ratio 2.08
-
Propeller Rotation Standard
-
Engine Trim and TiltManual Tilt - 5 stages / Power Tilt
-
Function
-
Electric StarterY
-
Battery Charging Capacity (AMP.) 12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm) 563
-
Dry Weight (kg) 49.5
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1240

-
BF15 SHSU
-
Feature
-
Engine
-
Engine Type OHC - 2 cylinders
-
Valves 4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 4,500 - 6,000
-
Rated Power (kW (PS)) 11
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery 1 carburettor with accelerator pump
-
Ignition System Electronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust System Through propeller boss
-
Gear Ratio2.08
-
Propeller Rotation Standard
-
Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
-
Function
-
Electric Starter Y
-
Battery Charging Capacity (AMP.) 12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm) 433
-
Dry Weight (kg) 49
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1110
-
With a 433mm shaft and 12A battery.

-
BF15 LHSU
-
Feature
-
Engine
-
Engine Type OHC - 2 cylinders
-
Valves 4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 4,500 - 6,000
-
Rated Power (kW (PS)) 11
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery 1 carburettor with accelerator pump
-
Ignition System Electronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust System Through propeller boss
-
Gear Ratio2.08
-
Propeller Rotation Standard
-
Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
-
Function
-
Electric Starter Y
-
Battery Charging Capacity (AMP.) 12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm) 563
-
Dry Weight (kg) 52
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1240
-
With a 563mm shaft and 12A battery.
.png)
-
BF15 LRTU
-
Feature Engine
-
Engine Type OHC - 2 cylinders
-
Valves 4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 4,500 - 6,000
-
Rated Power (kW (PS)) 11
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery 1 carburettor with accelerator pump
-
Ignition System Electronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust SystemThrough propeller boss
-
Gear Ratio 2.08
-
Propeller Rotation Standard
-
Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
-
Function
-
Electric Starter Y
-
Battery Charging Capacity (AMP.) 12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm)563
-
Dry Weight (kg) 58.5
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1240

​
-
BF15 XRTU
-
Feature
-
Engine
-
Engine Type OHC - 2 cylinders
-
Valves4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 4,500 - 6,000
-
Rated Power (kW (PS))11
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery1 carburettor with accelerator pump
-
Ignition SystemElectronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust System Through propeller boss
-
Gear Ratio 2.08
-
Propeller Rotation Standard
-
Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
-
Function
-
Electric Starter Y
-
Battery Charging Capacity (AMP.)12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm) 703
-
Dry Weight (kg) 61
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1380
.png)
-
BF20 SHU
-
Feature Engine
-
Engine Type OHC - 2 cylinders
-
Valves4 valves
-
Displacement (cc)350
-
Bore X Stroke (mm)59 x 64
-
Full Throttle Range (RPM)5,000 - 6,000
-
Rated Power (kW (PS))14.7
-
Cooling SystemWater Cooled (with Thermostat)
-
Fuel Delivery1 carburettor with accelerator pump
-
Ignition SystemElectronic PGM-IG
-
Starting SystemElectric / Recoil starter
-
Exhaust SystemThrough propeller boss
-
Gear Ratio2.08
-
Propeller RotationStandard
-
Engine Trim and TiltManual Tilt - 5 stages / Power Tilt
-
Function
-
Electric StarterY
-
Battery Charging Capacity (AMP.)12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm)433
-
Dry Weight (kg)46.5
-
Overall Length (mm)650 (Tiller) / 640 (Remote)
-
Overall Width (mm)350
-
Overall Height (mm)1110

-
BF20 SHSU
-
Feature Engine
-
Engine TypeOHC - 2 cylinders
-
Valves 4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 5,000 - 6,000
-
Rated Power (kW (PS)) 14.7
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery 1 carburettor with accelerator pump
-
Ignition System Electronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust System Through propeller boss
-
Gear Ratio2.08
-
Propeller Rotation Standard
-
Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
-
Function
-
Electric Starter Y
-
Battery Charging Capacity (AMP.)12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm) 433
-
Dry Weight (kg) 49
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1110

-
BF20 SHTU
-
Feature Engine
-
Engine Type OHC - 2 cylinders
-
Valves 4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 5,000 - 6,000
-
Rated Power (kW (PS)) 14.7
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery 1 carburettor with accelerator pump
-
Ignition SystemElectronic PGM-IG
-
Starting SystemElectric / Recoil starter
-
Exhaust SystemThrough propeller boss
-
Gear Ratio2.08
-
Propeller RotationStandard
-
Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
-
Function
-
Electric Starter Y
-
Battery Charging Capacity (AMP.)12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm) 433
-
Dry Weight (kg) 56
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1110

-
BF20 SRU
-
Feature Engine
-
Engine Type OHC - 2 cylinders
-
Valves4 valves
-
Displacement (cc)350
-
Bore X Stroke (mm)59 x 64
-
Full Throttle Range (RPM)5,000 - 6,000
-
Rated Power (kW (PS))14.7
-
Cooling SystemWater Cooled (with Thermostat)
-
Fuel Delivery1 carburettor with accelerator pump
-
Ignition System Electronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust System Through propeller boss
-
Gear Ratio 2.08
-
Propeller Rotation Standard
-
Engine Trim and TiltManual Tilt - 5 stages / Power Tilt
-
Function
-
Electric StarterY
-
Battery Charging Capacity (AMP.)12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm) 433
-
Dry Weight (kg) 49.5
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1110

-
Feature
-
Engine
Engine TypeOHC - 2 cylinders
Valves4 valves
Displacement (cc)350
Bore X Stroke (mm)59 x 64
Full Throttle Range (RPM)5,000 - 6,000
Rated Power (kW (PS))14.7
Cooling SystemWater Cooled (with Thermostat)
Fuel Delivery1 carburettor with accelerator pump
Ignition SystemElectronic PGM-IG
Starting SystemElectric / Recoil starter
Exhaust SystemThrough propeller boss
Gear Ratio2.08
Propeller RotationStandard
Engine Trim and TiltManual Tilt - 5 stages / Power Tilt
-
Function
Electric StarterY
Battery Charging Capacity (AMP.)12A (Electric) / 6A (Recoil)
-
Dimensions
Transom Height (mm)433
Dry Weight (kg)57
Overall Length (mm)650 (Tiller) / 640 (Remote)
Overall Width (mm)350
Overall Height (mm)1110

-
BF20 LHU
-
Feature Engine
-
Engine Type OHC - 2 cylinders
-
Valves 4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 5,000 - 6,000
-
Rated Power (kW (PS)) 14.7
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery 1 carburettor with accelerator pump
-
Ignition System Electronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust SystemThrough propeller boss
-
Gear Ratio 2.08
-
Propeller Rotation Standard
-
Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
-
Function
-
Electric Starter Y
-
Battery Charging Capacity (AMP.) 12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm) 563
-
Dry Weight (kg) 49.5
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1240

-
BF20 LHSU
-
Feature Engine
-
Engine Type OHC - 2 cylinders
-
Valves 4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 5,000 - 6,000
-
Rated Power (kW (PS)) 14.7
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery 1 carburettor with accelerator pump
-
Ignition System Electronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust System Through propeller boss
-
Gear Ratio 2.08
-
Propeller Rotation Standard
-
Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
-
Function
-
Electric StarterY
-
Battery Charging Capacity (AMP.)12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm)563
-
Dry Weight (kg)52
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1240

BF20 LHTU
-
Engine TypeOHC - 2 cylinders
-
Valves4 valves
-
Displacement (cc)350
-
Bore X Stroke (mm)59 x 64
-
Full Throttle Range (RPM)5,000 - 6,000
-
Rated Power (kW (PS))14.7
-
Cooling SystemWater Cooled (with Thermostat)
-
Fuel Delivery1 carburettor with accelerator pump
-
Ignition SystemElectronic PGM-IG
-
Starting SystemElectric / Recoil starter
-
Exhaust SystemThrough propeller boss
-
Gear Ratio2.08
-
Propeller RotationStandard
-
Engine Trim and TiltManual Tilt - 5 stages / Power Tilt
-
Function
-
Electric StarterY
-
Battery Charging Capacity (AMP.)12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm)563
-
Dry Weight (kg)57.5
-
Overall Length (mm)650 (Tiller) / 640 (Remote)
-
Overall Width (mm)350
-
Overall Height (mm)1240

BF20 LRTU
-
Engine Type OHC - 2 cylinders
-
Valves 4 valves
-
Displacement (cc) 350
-
Bore X Stroke (mm) 59 x 64
-
Full Throttle Range (RPM) 5,000 - 6,000
-
Rated Power (kW (PS))14.7
-
Cooling System Water Cooled (with Thermostat)
-
Fuel Delivery1 carburettor with accelerator pump
-
Ignition System Electronic PGM-IG
-
Starting System Electric / Recoil starter
-
Exhaust System Through propeller boss
-
Gear Ratio 2.08
-
Propeller Rotation Standard
-
Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
-
Function
-
Electric Starter Y
-
Battery Charging Capacity (AMP.)12A (Electric) / 6A (Recoil)
-
Dimensions
-
Transom Height (mm) 563
-
Dry Weight (kg) 57.5
-
Overall Length (mm) 650 (Tiller) / 640 (Remote)
-
Overall Width (mm) 350
-
Overall Height (mm) 1240
